Schneider Harmony XB4 LED Module 12V AC/DC White
Part Number: ZBVJ1
Sign in to see price & stockDelivery
We provide free delivery within a 100km radius of your local branch as part of our standard service. This applies to in-stock items and orders placed directly with your local branch.
Delivery is managed at the branch level, and restrictions may apply depending on order size, location, or access. Your branch will contact you to confirm any exceptions or additional details.
Collection
Collection orders will be ready to collect 2 hours after placing your order. This service applies to orders placed directly with your branch and is subject to stock availability.
Your branch will confirm collection details and advise of any exceptions where required.
- Signalling type: Steady
- Light source colour: white
- rated supply voltage: 12V AC DC
- Connections - terminals: screw clamp
- White light block operates with an integral LED, it is supplied with 12V AC DC and uses screw clamp terminals
- Light block allows fast and easy replacement and configuration of your signalling units
- Easily installed and replaced on compatible illuminated pushbutton or selector switch units via clip together assembly and connected with simple screw-clamp connection
- Enables visual distinction of signalling units via illumination by integral LED
- Vibration resistant screw clamp connection terminals ensure high vibration resistance making product suitable installation on high impact machines
- Colour
- White
- Guarantee
- 18 Months
- Ip Rating
- IP20
- Lamp Included
- Yes
- Lamp Type
- Integrated LED
- Light Source
- Integral LED
- Material
- Plastic
- Maximum Operating Temperature
- 70°C
- Minimum Operating Temperature
- -40°C
- Mounting
- Front Mounting
- Packaging Types
- Each
- Product Range
- Harmony XB4/XB5
- Standards
- IEC 60947-1 IEC 60947-5-5 IEC 60947-5-1 IEC 60947-5-4
- Type
- Light Block
- Unspsc V18
- 39122221
- Unspsc V24
- 39122221
- Voltage Range
- 12V AC DC
- Voltage Rating
- 12
- Weight
- 0.009kg
